Specifications
● Standard Class B with three times vacuum and drying, the remaining temperature of sterilized instrument is less than 0.2%.
● LCD display working status, touch keys.
● The vacuum data can reach -0.8 bar, it fits various instruments, including package, unpackaged, solid, hollow, multi-apertures, and inset pipes. It makes sure the instrument can be sterilized completely.
● Fully computer-controlled LCD display bright show. The interface is a modularized panel for easy operation.
● It is installed with BOWIE&DICK which measures the penetration of water steam.
● It has a vacuum test which can ensure the ability of vacuum testing.
● Fast and independent steam generator.
● Built-in mini printer which can record the sterilizing information.
● Equipped with Safety valve, Safety lock door system, Pressure lock system, Pressure or temperature overload protection, and Alarm system.
● It inactivates the HIV, HBV, BSE, and bacillus efficiently.
| MODEL/Technical Data | TM-35DV | TM-50DV |
| Sterilizing chamber volume | 35L | 50L |
| Φ300×500mm | Φ340×550mm | |
| Working pressure | 0.22Mpa | |
| Working temperature | 134℃ | |
| Temperature adjust range | 105-134℃ | |
| Timer range | 0-99min | |
| Heat average | ≤±1℃ | |
| Power | AC220V 50Hz/2.7KW | |
| Dimension(mm) | 550×850×500 | 600×850×560 |
| Exterior package dimension | 690×860×700 | 690×900×700 |
| G.W/N.W | 113kg/107Kg | 125kg/110kg |
